Thread Gauges
Plain Plugs & Rings
Aerosol Gauges
Length, Groove, Thickness & Diameter
Spline Gauges & Gear Metrology
3-Point Groove Measurement

Spline Gauges & Gear Metrology

Spline Gauges

  • Serration gauges
  • Straight-sided and involute spline gauges
  • Concentricity ring gauges
  • Indicating spline gauges
  • Work-holding mandrels

Spline Measurement

  • Indicating and Go/NoGo limit gauges
  • Plugs and rings
  • Involute, straight, serration, helical

All gauges are supplied in through-hardened tool steel and can be supplied with a UKAS calibration certificate.

Manufactured to BS, DIN or ISO specifications.

Spline Plug and Ring Gauges
Spline Plug and Ring Gauges

Master Gears

  • Helical master gears, 0.3 to 6 mod, to 45° helix angle
  • Spur master gears, 0.2 to 6 mod

All gauges are supplied in through-hardened toolsteel and can be supplied with either a factory or UKAS certificate.

Manufactured to BS, DIN or ISO specifications.

Master Gears Spline Ring Gauges
Master Gears Spline Ring Gauges

Gear Roll Testing

Options include single or double flank testing, manual or PC displays.

Gear roll testing
Gear roll testing

Involute & Helix Testers

  • Internal and external gear testing
  • Worm and bevel gear capabilities
  • Pitch, profile, helix angle and radial run-out
  • Involute and non-involute spline tests
  • Capacities up to 320mm diameter
  • Available with computerised scanning and evaluation or fully computer controlled, both with comprehensive results reporting
Involute and Helix testers
Involute and Helix testers
