Mitutoyo Dial Test Indicator Horizontal (Metric)

Any questions, contact us?

How to contact us

UKAS Calibration Lab

Why use Rhopoint

Frequently Asked Questions

FAQs

What can we calibrate?

Calibration disciplines

SKURange (mm)FeatureStylus LengthPrice
513-401-10E0 - 0.14Basic set14.7mm£128.00

Add to Basket

513-405-10E0 - 0.2Basic set18.7mm£122.00

Add to Basket

513-405-10A0 - 0.2Plus set18.7mm£130.00

Add to Basket

513-405-10T0 - 0.2Full set18.7mm£146.00

Add to Basket

513-424-10E0 - 0.5Basic set22.2mm£111.00

Add to Basket

513-414-10E0 - 0.5Basic set37.4mm£122.00

Add to Basket

513-424-10T0 - 0.5Full set22.2mm£137.00

Add to Basket

513-414-10T0 - 0.5Full set37.4mm£161.00

Add to Basket

513-425-10E0 - 0.6Basic set18.7mm£142.00

Add to Basket

513-425-10A0 - 0.6Plus set18.7mm£151.00

Add to Basket

513-404-10E0 - 0.8Basic set20.9mm£98.70

Add to Basket

513-404-10A0 - 0.8Plus set20.9mm£104.00

Add to Basket

513-404-10T0 - 0.8Full set20.9mm£122.00

Add to Basket

513-908-10E0 - 0.8Basic set - with magnet stand20.9mm£174.00

Add to Basket

513-415-10E0 - 1Basic set44.5mm£124.00

Add to Basket

513-415-10A0 - 1Plus set44.5mm£120.00

Add to Basket

513-415-10T0 - 1Full set44.5mm£150.00

Add to Basket

513-426-10E0 - 1.5Basic set22.2mm£114.00

Add to Basket

513-426-10A0 - 1.5Plus set22.2mm£114.00

Add to Basket

Prices in the above table do not include calibration.

Description

A Mitutoyo versatile anti-magnetic type lever indicator (or dial test indicator, DTI) suited to alignment operations on machine tools and similar applications. This indicator automatically adapts to the required measuring direction on contact, and the jewelled movement provides lowest friction and stiction for smooth and precise operation. Supplied with a basic set of mounting accessories.

Specification

Weight 45 g
Family

Unit

Calibration Type

Indicator Type

Lever Type

Range (mm)

, , , , , ,

R MPE (Repeatability) (µm)

3, 1

Graduation (mm)

, ,

Feature

Basic set, Basic set – with magnet stand, Full set, Plus set

MPE measuring range (µm)

1, 10, 16, 3, 5, 7, 8

Measuring force

, , , ,

Scale

0-100-0, 0-25-0, 0-40-0, 0-50-0, 0-70-0

MPE any 1/2 revolution

3, 6, 8

MPE any 1 revolution

10, 5

Carbide stylus tip ø2 mm No.

103006, 103010, 103011, 131324, 136013, 137557

Digital/Analog

Contact point

Stylus Length

14.7mm, 18.7mm, 19.9mm, 19mm, 20.9mm, 22.2mm, 33.9mm, 37.4mm, 44.5mm
